Specification
Camera
| Model | CMU2202 |
| Sensor | 1/2.8″, 2.0 megapixel, progressive scan, CMOS |
| Lens | 2.8mm@F2.0 |
| Angle of View (H,V) | 106.7°,57.1° |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Minimum Illumination | Colour: 0.01Lux (F2.0, AGC ON) OLux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| S/N | >52dB |
| IR Range | Up to 30m (98ft) IR range |
| IR On/Off Control | Auto/Manual |
| Defog | igital Defog |
| WDR | DWDR |
Video
| Video Compression | Ultra 265, H.265, H.264 |
| Resolution | Main Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps Sub Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF, Max 30fps; CIF, Max 30fps |
| Video Bit Rate | 128 Kbps~16 Mbps |
| Support | Motion Detection , Privacy Mask |
| White Balance | Auto/Outdoor/Fine Tune/ Sodium Lamp/ Locked/Auto2 |
| Digital noise reduction | 2D/3D DNR |
| Smart IR | Supported |
| Flip | Normal/ Vertical/ Horizontal/ 180° |
| HLC | Supported |
| BLC | Supported |
Network
| Protocols | IPv4, IGMP, ICMP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, UPnP, HTTP |
| Web Browser | Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+ |
| Network | 10/100M Base-TX Ethernet |
General
| Power | DC 12V+25%, PoE (IEEE 802.3af) Power consumption : Max 5.0W |
| Working Environment | -30°C ~60°C (-22°F ~ 140°F), Humidity : <95% RH (non-condensing) |
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity : <95% RH (non-condensing) |
| Ingress Protection | IP67 |
| Vandal Resistant | IK10 |
Description
สัญญาณภาพคมชัด กล้องวงจรปิด hip รุ่น CMU2202 ปลอดภัยทุกพื้นที่ ตอบโจทย์ CCTV HIP คุณภาพ ภาพคมชัดระดับ Full HD
• High quality image with 2MP, 1/2.8″CMOS sensor
• 2MP (1920*1080)@30/25fps; 720P (1280*720)@30/25fps
• Ultra 265, H.265, H.264
• Smart IR, up to 30m (98ft) IR distance
• Day/night functionality
• 2D/3D DNR (Digital Noise Reduction)
• IP67 protection
• IK10 vandal resistant
• Support PoE power supply
• 2-Axis
(ขอสงวนสิทธิ์ในการเปลี่ยนแปลงรายละเอียดโดยไม่ต้องแจ้งให้ทราบส่วงหน้า bangkokfinger.com )
